Hot Runner Coil Heater


Hot Runner Coil Heater

Euro Tech Hotrunner System is a dependable Manufacturer and Exporter of Hot Runner Coil Heater. We offer the finest Hot Runner Coil Heaters that are made of nickel chrome resistance wire, placed inside chrome nickel steel tube filled with MGO powder and compacted for faster and efficient heat transfer. Our Hot Runner Coil Heater is annealed to acquire malleability for bending into any shape. Hot Runner Bushes are produced with hot runner heaters of different cross sections with inner brass and outer stainless steel cover.

Applications
  • Moulds & dies
  • Manifolds
  • Hot runner nozzles and spruce bushes
  • Packaging machinery
  • Manifolds
  • Injection molding machine nozzle


Technical Specifications

Sheath Material MGO
Resistance Wire NI Cr 80-20
Maximum Sheath Temperature 700o
Die electric Strength 800 VA/C
Insulation >5 M W
Thermocouple J Type (Standard) or K Type
Length Tolerance (Straight) 5%
Wattage Tolerance 10% (5% Available Upon Request)
REsistance Tolerance 10% (5% Available Upon Request)
Unheated Length 35 mm Standard
Dimension Tolerance Coil I.D. 0.1 to 0.2 mm
